KOBOK Mt Blanc Grand Design 1370 Wood Fireplace with Vertical Door

18kW

Nominal Power Output

270-525m2

Heatable Area

6kg/h

Hourly Consumption

Totally unique fireplace inserts grand in design, size and construction. Impressive heat output, yet clean efficient combustion and unparalleled ambience. Suitable for large spaces or special effect applications.

Features

• Deep focus for aesthetic burning
• Primary and Secondary Air / Three-Stage Combustion
• Hygienically safe ecological varnish
• Possibility of air supply for combustion
  from external environment
• Height-adjustable position by means of set screws
• High glass purity when burning
• Preparation for automatic combustion control
• All-sand construction of the fireplace insert
  before surface treatment
• Automatic combustion control possible

Specifications

Door Dimensions (w h) : 1260/480mm

Overall Dimensions (w h d) : 1370/1500/545mm

Weight: 440kg

Flue Outlet: 9"

Air Supply Duct: 2x125mm

Minimum Hearth Dimensions (w d) : 1800/850mm

Log Length/Diameter: 60/45cm

Average Wood Consumption: 6kg/hr

Average Efficiency EU: 80%

Nominal Heat Output: 18kW

Maximum Heat Output: 35 kW

Door Opening System: Lift

Manufacturer: Kobok

Flue Options

9" Zero Clearance Flue Kit

Downloads

PRODUCT BROCHURE (PDF)

INSTALLATION & OPERATING MANUAL (PDF)

Installation

Need someone to install your fireplace? Find out how we can help.

Flueing and Accessories

• Flueing or accessories are not included in the price
• Before placing your order please contact our sales team on 02 8358 6000 to discuss your requirements
